Revit for BIM: Structural and Architectural Elements Explained

Revit, a BIM software by Autodesk, has become an industry standard for architectural design and documentation. BIM goes beyond traditional 2D drafting by creating a virtual model of a building with intelligent objects. These objects hold not just geometrical data but also embedded information about materials, properties, and functionalities.

One of the key advantages of BIM is its ability to facilitate collaboration between different disciplines involved in a construction project. Architects, structural engineers, and MEP (Mechanical, Electrical, and Plumbing) engineers all work on different aspects of the building but need their designs to seamlessly integrate. Revit achieves this by offering discipline-specific tools and functionalities.

This blog post takes a look into the area of structural and architectural elements in Revit, exploring their differences and how they contribute to a collaborative BIM workflow. We'll also look into how architectural and structural templates differ and how they can be used to streamline the design process.

Architectural Elements: Defining the Building Form

Revit Architecture is a software module specifically designed for architects. It provides a comprehensive toolkit for creating and managing architectural elements that define the overall form and aesthetics of a building.

Here are some of the key architectural elements in Revit:

• Walls: Walls can be straight, curved, or contain complex profiles. They can be assigned various materials, thicknesses, and fire ratings.

• Doors & Windows: A vast library of doors and windows with customizable properties like size, material, and opening behavior is available.

• Floors: Revit allows for creating floors of different types like slabs, decks, and roofs. They can be sloped or flat, with customizable materials and finishes.

• Ceilings: Similar to floors, ceilings can be flat, sloped, or follow complex geometries. They can be modeled with various materials and finishes.

• Stairs & Railings: Revit offers tools for creating straight, curved, and spiral staircases with customizable treads, risers, and railings.

• Masses & Curtaing Systems: For early-stage design exploration, architects can utilize masses, which are 3D forms representing building components. Curtaing systems allow for efficient modeling of building envelopes.

These elements hold not just geometric data, but also parametric information. This allows architects to make changes to a design element, and the software automatically updates all related elements and documentation.

BIM model_©chapmantaylor.com

Structural Elements: The Building's Skeleton

Revit Structure, another module within Revit, caters to the needs of structural engineers. It provides tools for creating and analyzing structural elements that form the building's load-bearing skeleton.

Here are some of the key structural elements in Revit:

• Columns: Revit offers a variety of column types, including concrete, steel, and composite columns. They can be sized and positioned with precise control.

• Beams & Trusses: Structural beams and trusses can be modeled with various materials, sections, and lengths. They can be connected to columns and walls to create a load-bearing structure.

• Braces: Braces can be used to provide lateral stability to the structure and resist wind and seismic loads.

• Foundations: Revit allows for modeling different foundation types like spread footings, pile foundations, and slabs-on-grade.

• Structural Rebar: Reinforcement bars for concrete elements can be modeled and detailed within Revit.

These structural elements can be assigned material properties, loads, and boundary conditions. Revit then performs structural analysis to determine forces, stresses, and deflections in the structure. This analysis helps engineers ensure the building can safely withstand anticipated loads.

Collaboration through Linked Models and BIM Workflows

While Revit offers discipline-specific functionalities, its true power lies in its ability to facilitate collaboration between architects and structural engineers. Here's how BIM workflows achieve this:

• Linked Models: Architectural and structural models can be linked within a single Revit project environment. This allows each discipline to work on their own model while referencing the other's work.

• Clash Detection: Revit can identify clashes between architectural and structural elements, allowing for early detection and resolution of conflicts.

• Coordination Meetings: With all models linked, project teams can hold virtual coordination meetings to discuss design decisions and identify potential issues.

Architectural vs. Structural Templates: Streamlining the Design Process

Both Revit Architecture and Revit Structure offer project templates. These pre-configured files provide a starting point for a project with discipline-specific settings, content libraries, and families.

Architectural Templates

These templates typically include pre-loaded wall types, door and window families, and materials commonly used in architectural design. They may also include settings for grids, levels, and annotations specific to architectural drawings.

Structural Templates:

Structural templates provide pre-defined column, beam, and foundation families commonly used in structural engineering. They may also include analytical settings, material properties, and load definitions relevant for structural analysis.

BIM model_©parametric-architecture.com on Pinterest.com

Choosing the Right Template and Benefits of Customization

Selecting the appropriate template for your project ensures a smooth workflow from the outset. Here are some factors to consider:

• Project Type: Templates are often categorized by building type, such as residential, commercial, or industrial. Choosing a template relevant to your project provides a foundation of elements and settings specific to that building type.

• Company Standards: Many architectural and engineering firms establish their own internal standards for Revit projects. These standards may dictate specific content libraries, families, and annotation styles. Choosing a template aligned with your company's standards ensures consistency across projects.

• Level of Detail: The level of detail required in the initial stages of the project can also influence template selection. Some templates offer basic elements for early design exploration, while others provide more detailed content for advanced modeling.

While templates offer a valuable starting point, customization is key to optimizing the BIM workflow for your specific project needs. Here are some ways to customize Revit templates:

• Content Libraries: You can add or remove families from the template's content libraries to ensure you have the specific elements required for your project. This can include custom door and window families, furniture elements, or structural connection details.

• Material Definitions: Templates often come with pre-defined materials. You can modify these materials or add new ones specific to your project requirements.

• Project Settings: Several project settings can be customized within the template, including units, grids, levels, and annotation styles. Tailoring these settings streamlines the modeling process and ensures project documentation adheres to specific standards.

Beyond the Basics: Advanced Collaboration Techniques with Revit

Revit offers a range of advanced tools that further enhance collaboration between architects and structural engineers:

• Worksharing: This functionality allows multiple users to work on the same Revit model simultaneously, preventing conflicts and ensuring efficient project progress.

• Design Options: Design options are a powerful tool for exploring different design variations. Changes made within a design option are isolated from the main model, allowing for side-by-side comparisons and informed decision-making.

• Dynamo: For more complex automation tasks, Dynamo, a visual programming tool for Revit, can be used to create custom scripts for automating repetitive tasks or streamlining data exchange between disciplines.

By leveraging these advanced tools, architectural and structural teams can achieve a truly collaborative BIM workflow, leading to improved design quality, reduced errors, and enhanced project efficiency.

Conclusion

Revit's ability to differentiate between architectural and structural elements fosters clear communication and streamlined workflows between architects and structural engineers. By utilizing linked models, BIM workflows, and project templates, BIM software removes the traditional barriers between disciplines, enabling a truly collaborative design environment. This collaborative approach leads to better-coordinated designs, fewer errors, and ultimately, successful building projects.
